Chemical Composition of SS Buttweld Fittings
| Grade | Ti | H | C | Fe | N | Al | O | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade2 | 99.2 min | 0.015 max | 0.1 max | 0.3 max | 0.03 max | – | 0.25 max | – |
| Ti Grade5 | 90 min | – | – | 0.25 max | – | 6 min | 0.2 max | 4 min |
| Grade | Ti | H | C | Fe | N | Al | O | V |
|---|---|---|---|---|---|---|---|---|
| Ti Grade5 | 90 min | – | – | 0.25 max | – | 6 min | 0.2 max | 4 min |
Mechanical Properties of SS Butt weld Pipe Fittings
| Element | Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 2 | 1665 °C (3030 °F) | 4.5 g/cm3 | Psi – 39900 , MPa – 275 | Psi – 49900 , MPa – 344 | 20 % |
| Titanium Gr. 5 | 1632 °C (2970 °F) | 4.43 g/cm3 | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
| Element | Melting Point | Density | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
|---|---|---|---|---|---|
| Titanium Gr. 5 | 1632 °C (2970 °F) | 4.43 g/cm3 | Psi – 128000 , MPa – 880 | Psi – 138000 , MPa – 950 | 14 % |
